HxGN AgrOn Guidance: Orientation system that maintains positioning for tractors

Orientation system that maintains positioning for tractors, machinery and agricultural and forestry equipment.

Ready to get started?

Talk to an expert and discover what Hexagon can do for your organization.

Guides and maintains machine positioning through arrows and virtual direction lines for the operator to reference – aiming to maintain planned alignment and obtain greater speed, practicality and quality. It’s used when there’s a need to determine the correct alignment and is an aid in identifying locations for soil preparation, fertilisation, bait, limestone and herbicides applications. The product is configurable and enables straight lines, curves and pivots. It also saves resources by calculating the best possible use of the work area.

Characteristics and features:
  • Includes multiple orientation options: straight, curved, pivot, adaptative, and custom made on a Farm Management System (FMS)
  • Loads map into system and enables control over the applied area
  • Light bar, set of indicators on the screen, to inform the operator where to steer the vehicle
  • 2D and 3D view
  • Boundary maps
  • Odometer, information on distance covered via satellite positioning. Useful to reduce the risk of vinasse hoses damage when stretching it through the field.
  • Flags marking, allows marking objects on the map to improve orientation in low visibility
  • Integrated with the Ti5, Ti7, or Ti10 display
  • Has the additional Remote Access module
  • Optimises work area
  • Better machine alignment
  • Reduce overlap
  • Operation agility
  • HxGN AgrOn Guidance | Remote Access

    Learn more about the add-on module:

    System for remote access to displays for technical assistance and calibrations.

    Through an internet connection, it is possible for technical staff to view the display helping solve problems that arise in real-time. It is an exclusive and available service for all products that are enabled in the displays.


    • Remote monitoring of the machine
    • Ensures fast, efficient and cost-effective service
    • Accepts differents Internet connections: cable, Wi-Fi, 4G, 3G and even 2G
    • Allows technical team to view the display screen and control if needed


    • Fast service
    • Reduces cost service
  • Displays

    The displays allow users to use Hexagon Precision Agriculture solutions. They are compatible with several machines on the market and meet the needs of each customer – with the possibility of including only one or even all products in a single display.



    • Automating machine operations
    • Real-time monitoring
    • Optimising the agricultural and forestry operations
    • Using resources wisely

    Farming accuracy:

    • GNSS L1 10Hz - GPS with EGNOS/WAAS 2,0 m (absolute)
    • GNSS L1 20Hz - GPS with EGNOS/WAAS 15-20cm (pass to pass, 15min)
    • GNSS L1/L2 20Hz - GPS/Glonass 10cm (pass to pass, 15min)
    • GNSSL1/L2/Lband 20Hz - GPS/Glonass/TerraStar 2,5cm (absolute)
    • GNSSL1/L2/Lband 20Hz - GPS/Glonass/RTK 2 cm (absolute)


    Characteristics  Ti5
    Ti7 Ti7 chart
    Ti10 Ti10 chart
    Screen size 5" LCD
    7" LCD
    10.1" LCD
    Processor Single core 800 MHz 1x ARM Cortex-A9
    Single core 800 MHz 1x ARM Cortex-A9 Quad Core 1.2 GHz 4x ARM Cortex-A35
    Storage capacity
    RAM: 1 GB DDR3
    FLASH: 4 GB eMMC
    RAM: 1 GB DDR3
    FLASH: 4 GB eMMC
    RAM: 2 GB DDR3
    FLASH: 32 GB eMMC
    Screen configuration
    16M colours, 600 cd/m2 brightness and 600:1 contrast
    265K colours, 1000 cd/m2 brightness and 400:1 contrast
    16Mcolors, 1000 cd/m2 brightness, 800:1 contrast
    Resolution 800×480
    1280x800 (HD)
    Display size
    162 mm (W) × 125 mm (H) × 45 mm (L)
    208 mm (W) × 159 mm (H) × 57 mm (L)
    177 mm (W) x 250 mm (H) x 47 mm (L)
    Sturdy aluminium case
    High contrast and configurable lighting for different visibility conditions
    No No
    5MP Front Camera*
    Audio system with built-in speaker and microphone
    2W speaker Front microphone for audible alerts
    Multi-language support
    Yes Yes
    Wi-Fi 2.4GHz*
    No Optional Yes
    Record of detailed information of operations and export/transmission of files
    Yes Yes Yes
    Digital Radio 900MHz or 433Mhz*
    No Optional Optional
    4G+ cell phone with 28 band support (700MHz)*
    No Optional Optional
    No Optional Bluetooth 5.0
    User Entry
    Touch screen and Power button Touch screen and Power button Touch screen and Power button
    - - Li-Ion 4.900 mAh*
    No Yes Yes
    Quantity of products per equipment**
    Up to 3 No limit No limit
    External map reading in shape (.shp) format, prepared in the office
    Yes Yes Yes
    Protection Index
    IP65 IP64 IP66, IP67
    Power supply
    12Vdc 12Vdc 12Vdc
    Operating temperature
    -20°C to 60°C -20°C to 60°C -20°C to 70°C
    Storage temperature
    -30°C to 80°C -30°C to 80°C -30°C to 80°C
    USB (x1), CAN (x1) and RS-232 (x1) USB (x1), CAN (x2) and RS-232 (x2) USB (x2), CAN (x3) and RS-232 (x2)

    * check the communication available for each model

    ** Ti5 compatible with AgrOn Electric Auto Steering, AgrOn Guidance and a product to choose from
