HxGN AgrOn Track Controller: Electromechanical steering system for agricultural vehicles

Motor for automatic electromechanical steering system that provides a retrofit solution for most models of tractors, sprayers and harvesters available on the market. The mechanical and electronic connection design allows easy and fast installation and/or exchange, in addition to having a simple drive.

Characteristics:

• Electric drive.
• It has an additional module with an inertial navigation unit, improving the estimate of the vehicle's orientation in combination with a satellite positioning system and also compensating for the position on sloping terrain.
• Possibility to operate in conjunction with external controllers (ECU).
• Easy integration with controllers from other manufacturers. Being able to control the direction of the vehicle or only the position of the steering wheel.
• Accuracy of steering wheel position by 2.74 degrees.

• Brushless DC motor with integrated planetary gearbox
• Specifically designed adaptor for steering column
• Handwheel sensor when integrated into the ECU
• Remote Engage Switch
• Harness integrated power switch
• Power: 12V - 10A max peak
• Max Speed: 200 RPM
• Rated Torque @ 160 RPM: 4.01 Nm
• Stall Torque: 5.65 Nm
• Weight: 2,65Kg
• Operating temperature: -40°C to 85°C
• Storage temperature: -40°C to 85°C
• Compliance: CE, RCM and FCC PART 15
• Vibration compliant with MIL-STD-810G, METHOD 514.6, CATEGORY 24 7.69 Grms and IEC 60068-2-6: Sinusoidal (5g, 10-200Hz)
• Mechanical shock compliant with MIL-STD-810G, METHOD 516.6 PROCEDURE 1 SAWTOOTH - 40G, 1ms
