HP-THDe Touch Trigger Probe

The HP-THDe touch trigger probe has been designed to take advantage of cutting-edge technology and deliver highly accurate touch trigger probing with styli builds of up to 100 mm. It offers high-precision repeatability and low 3D form error thanks to a highly innovative opto-mechanical design capable of detecting nanometric movements in the X, Y and Z directions.


A touch trigger probe with 6 probing points during an inspection routine. The artefact being inspected in mounted on a fixturing system.

Guaranteed accuracy
Unlike standard probes which employ a mechanical switch to create probing points which leads to small form errors sometimes called ‘lobbing’ the mechanical design of the HP-THDe touch trigger probe overcomes this force and delivers very low lobbing in all six probing directions.
A probe rack holding 6 touch trigger probes. Each probe is of a different length.

Maximised versatility
The HP-THDe is a modular probe. Modules can be changed rapidly without the need for calibration using the existing HR-P passive rack. The probe is also compatible with existing Hexagon extensions and styli.
A close up of a touch trigger probe inspecting an engine block

Extended durability
The robust design of the HP-THDe protects it perfectly against contamination and collisions. Also, thanks to the optomechanical technology, the HP-THDe lasts for up to 10 million individual measurement points.
HP-THDe sensors are available on these systems
  • Features & benefits

    TargetExcellent repeatability and 3D performance with styli lengths up to 100 mm
    The HP-THDe touch trigger probe is recommended for applications with tight tolerance and those that require a high level of point density and high-speed measurement. It is also suited to applications that require long styli builds.

    SensorAdaptive triggering
    Unlike other systems on the market, HP-THDe has an adaptive trigger than can be controlled by the measuring software and machine controller. The trigger parameters are automatically adjusted when loading a new stylus build, ensuring optimal measuring performance at all times.

    Real-TimeEnhanced productivity
    The HP-THDe benefits from a fast stylus change and increased module life compared to a typical touch trigger probe, therefore productivity is enhanced saving both time and cost.

    PickaxeRobustness
    The HP-THDe has been designed to be as robust as a standard touch trigger probe, reducing downtime and cost of ownership.

  • Technical data
       HP-THDe-SF
    (Standard Force)    		  HP-THDe-MF
    (Medium Force)    		  HP-THDe-EF
    (Extended Force)
     Weight (Body and module)  21.8g
     Mounting  M8 with active 1 wire connection
     Module changer rack  HR-P / HR-MP
     Suitable interface  HH-C-V2.1 or higher
     Max. probe head extension 750 mm (HH-A-H2.5)
    450 mm (HH-A-T2.5)
    300 mm (HH-A-T5 or HH-A-T7.5)
    200 mm (HH-A-M5 or HH-A-M7.5)
     Probing direction  6 Way ±X, ±Y and ±Z
     Stylus mounting  M2 thread
     Max. straight styli length  30 mm   50 mm (75 mm CF)  75 (100 mm CF)
     Configuration of a touch trigger probeMax. star styli  dimensions*1  N/A A (Length): 40 mm
    B (Extension): 20 mm
    C (Span): 15 mm    		 A (Length): 50 mm
    B (Extension): 20 mm
     C (Span): 30 mm


    Measuring Performance

       HP-THDe-SF
    with 10 mm stylus    		   HP-THDe-MF
    with 10 mm stylus    		 HP-THDe-MF
    with 50 mm stylus    		  HP-THDe-EF
    with 10 mm stylus    		  HP-THDe-EF
    with 50 mm stylus
     Overtravel force
     (XY plane)    		  Max. 0.3 N  Max 0.49 N  Max. 0.16 N  Max 065 N  Max. 020 N
     Overtravel force
     (Z plane)    		  1.00 N  1.8 N 1.80 N  2.35 N  2.35 N
     Trigger force (XY plane)  0.05 N  0.05 N  0.02 N  0.05 N  0.02 N
     Trigger force (Z plane)  0.80  N  0.80 N  1.50 N  0.80 N  1.65 N
     Form error*2
     2D
     3D    		  0.8µ
     1.3 µ    		  0.8µ
     1.3 µ    		  1.6 µ
     2.0 µ    		  0.8 µ
     1.3 µ    		  1.6 µ
     2.0 µ
     Unidirectional   repeatability 2σ *2  0.3 µm  0.3 µm  0.4 µm  0.3 µm  0.2 µm

    *2 Test conditions: Straight stylus, Touch speed 5 mm/sec.
