HP-T-RP Probe
HP-T-RP - The rugged touch trigger probe for harsh environments

Ready to get started?
-
Features & benefits
- Compact 5 Way Probe
- High degree of over travel
- Adjustable trigger force
- Rugged design
-
Technical data
Measuring directions ±X, ±Y, +Z Stylus force 0,11 N to 0,30 N Repeatability 1D (2 Sigma) 0,35 µm Probe mounting M8 Stylus mounting M3 Overtravel X/Y: ± 22,0°, Z: 5,5 mm (with 0,11 N), 2,0 mm (with 0,30 N) Probe extensions L = 300 mm max. using the HH-A Probe Head Stylus length Up to 100 mm Probe weight 43 g -
