Electronic Control Unit with ISOBUS communication

The ISOBUS Control kit is an Electronic Control Unit designed to control solid fertiliser rate and sections via hydraulic actuation, interfacing with sensors and actuators on agricultural and forestry implements through ISOBUS communication.

Product Features:

• Controls up to three application input rates simultaneously
• Ideal for controlling and monitoring variable-rate fertilisation operations
• Compatible with ISOBUS displays via Virtual Terminal and Task Controller
• Adjustable for your implement, with customised operational rules and dynamic configurations
• Robust and reliable device for operation in harsh environments
• Simple and practical operation and calibration
• Enhanced precision in section control, considering the new model for positioning trailed implements.

Learn more about the technical specifications of the ISOBUS Control kit:

Characteristics	ISOBUS Control kit
Performance	RM Cortex-M7 400 MHz Fash memory 16 MB RAM memory 256 kB 128 kB non-volatile memory
Communications	2x CAN bus
Outputs (PWM)	3x half bridge (up to 10A per channel) 4x half bridge (up to 3A per channel) *Total output current: 14A
Inputs	4x digital inputs ** 2x analog input ** 2 inputs shared with outputs
Inertial Measurement Unit	6 axis inertial sensor
Power supply	12 VDC or 24 VDC nominal voltage Voltage range: 7-36 VDC
Protection Index	IP67
Operating Temperature	-40 to +105 ºC
Approvals	CE e RMC Vibration and Shock WEEE RoHS
