Leica Absolute Tracker AT500
Measure anywhere with enhanced productivity
Would you like to know more?
The Leica Absolute Tracker AT500 makes measurement simple without compromising on portability, productivity and resilience. From transport case to large-scale measurement is just a matter of moments thanks to a hassle-free setup process, while IP54-rated protection and an extended operating temperature range keep the AT500 working under even the most challenging conditions. From reflector measurement at up to 160 metres from the tracker to simplified 6DoF probing functionality, the AT500 is ready for every manufacturing and assembly challenge, no matter the size or location.
Introducing Leica Absolute Tracker AT500
Here is what makes the AT500 unique
The AT500 is our easiest ever laser tracker. Out of the transport case, power on and you’re ready to measure. There are no cables thanks to the built-in controller and battery power, as well as no levelling or reflector initialisation required. The system runs on two IATA compliant batteries, hot-swappable and offering up to 6 hours of runtime. Measurement is faster too – at a 100 Hz, point collection is 10 times faster than the AT403, while the latest generation of our patented PowerLock automatic targeting system avoids time wasting. The system is also augmented by the new AT500 Connect App, which allows network setup and levelling to be performed on your smart phone or tablet (available for Android and iOS).
The B-Probeplus delivers a completely new user experience for entry-level probing. Completely wireless measurement now comes with live feedback and a wide acceptance angle of up to 16° in any direction at a range of up to 12 metres from the tracker. The new probe unit also features redesigned, more durable buttons and an extended battery runtime of up to 6 hours, along with probing measurement accuracy specified in line with ISO 10360-10.
The AT500 boasts IP54-rated protection from the elements, as well as an extended working temperature range of -15 to +50°C, allowing for measurement from the mountaintop to the foundry. And thanks to the all-in-one integrated design with built-in controller – a first for an Absolute Tracker system – the AT500 is more portable than ever.
Features and benefits
All-in-One Integrated Design
From built-in battery-powered controller unit, integrated wireless connectivity, environmental monitoring and all-day battery power, to HD overview camera and ergonomic carry handle, every need is built in.
Single-Box Probing System
Just one case contains the lightest and most portable sensor and probe as well as IR remote, with various transportation case options for full flexibility.
Smart Connectivity
Built-in WiFi with true access-point functionality delivers single-user operation through a simple PC setup and remote control.
Bluetooth Control
The AT500 Connect app offers quick settings adjustments over Bluetooth direct from a smartphone or tablet (Android and iOS).
PowerLock
Automatically re-establishes interrupted line of sight within a wide field of view with no user interaction required.
Continuous Measurement
Continuous time and distance measurement mode, with measurement sampling rate at 100 Hz.
Entry-Level Probing
Cableless, battery-powered Leica B-Probeplus with customisable hidden-point capability.
IP54 Certification
The IEC-certified sealed unit guarantees ingress protection against dust and other contaminants, enabling effective measurement in even the harshest environments.
MeteoStation
Integrated environmental unit monitors conditions including temperature, pressure and humidity to compensate for changes and ensure accurate measurements regardless of external factors.
Orient-to-Gravity
Enables measurement with the Z-axis aligned to gravity, ideal for levelling and alignment tasks.
Battery Power
Independent hot-swappable battery power supply allows for quick and easy cable-free setup and all-day wireless operation.
Operating Temperature
Wide operating temperature range of -15 to +50° Celsius.
Measurement Volume
Ultra-large measurement volume of up to 320 metres (ø), with minimum measurement distance less than 0.8 metres.
Hexagon Guarantee
Full 24-month factory warranty and guaranteed ten years of serviceability.
See the Leica Absolute Tracker AT500 in action
Watch videos from across industry of the ATS800 in action to see how it is currently being used to overcome challenges like yours.
Leica Absolute Tracker AT500: Productive shop-floor measurement with reflectors and the B-Probeplus
Leica Absolute Tracker AT500: Productivity features and accessories
Pienergies – Saint-Égrève, France
Learn more ➜
Streamlining precision: Elevating training with laser tracker and Inspire software
Leica Absolute Tracker AT500: The multifunctional 3D laser tracker
Leica Absolute Tracker AT500: The ultra-portable, ultra-usable 3D laser tracker
AT500 Accessories
-
The Absolute Tracker range
Built for precision and productivity
Hexagon's Absolute Tracker range is designed to support a wide variety of industries and applications, delivering precise measurements and efficient workflows. Whether you need high-accuracy reflector measurements or large-scale surface scanning, there’s a tracker for your needs.
Two categories for versatility:
Absolute Trackers: Ideal for reflector and probing tasks with exceptional accuracy and reliability.
- AT960: The ultimate 6DoF tracker for both manual and automated inspection.
- AT930: High-accuracy 3D tracking for precise dynamic reflector measurements.
- AT500: Ultra-portable and long-range for flexible measurement anywhere.
Direct Scanning Absolute Trackers: Designed for non-contact measurements and complex surface inspections.
- ATS800: Precise scanning for features and surfaces up to 40 metres.
- ATS600: Fast and accurate scanning for large surfaces up to 60 metres.
-
Industries and applications
Improved metrology for your industry
Some of the places you can measure- Aerospace
- Automotive
- Energy & Power Gen
- Industrial Equipment
- General Manufacturing
- Education & Research
- Defence
- Marine
- Construction
- Heavy Machinery
- Agriculture
- Motorsport
More uses than everSome of the tasks you can now complete
- Build & Inspect jig and fixtures
- Metrology Assisted Assembly
- Sheet metal inspection
- Mould and die
- Additive manufacturing
- Machine and robot calibration
- On-machine verification
- Composite part inspection
- In-process checks
- Virtual assembly
- Real-time machine path correction
- Maintenance and repair
- Reverse engineering
- BIW InspectionFlush & Gap
- Precise marking operations
- Completeness checks
- Metrology Assisted
- Construction
- Hot part inspection
- Precise mirror alignment
-
